PIR Motion Sensor Lighting Switch

This sensor switch can be installed easily with any 220ac voltage lamb to control its on/off automatically as described below.

Type: PIR Switch
Adjust the light soft and stable, no flickering.
You can conveniently to let the light auto on/off .The switch can detect human body’s infrared , and use infrared to control the load
Users according to actual needs, the human body sensors installed in the appropriate environment
Power supply: AC 110~250v 50~60Hz
Load power: 5W~200W
Sensor distance: 5~8m
Dimension: Approx 86*86*12mm
Weight: Approx 80g
Color: White
Applications: Incandescent lamp, energy-saving lamps, LED lamp, fluorescent lamp and other kinds of loads
Easy to install and simple to use

Functions & Features

Automatic induction: when people enter into the range of induction, it will turn on, when people leave, it will turn off with delay.
It can be applied to corridor ,passageway, toilet, basement, warehouse, garage, etc., which have the function of automatic lighting, and control.
Photosensitive control: it adopting photoactive control, it doesn’t turn on during daylight or in strong light environment..Automatic random delay: After it turns on, in the delay period, if there is presence of people, it keeps on working until people leave, than turn on with delay.
Status indicator: efficient LED indicator, which is easy for installation and fault analysis.
Temperature compensation: include specialized temperature compensation chip, which used to reducing the effect of temp. on detecting distance
