Save -30% Out of stock 1N4007 Through Hole Diode (Pack of 1000) High Quality

1N4007 Through Hole Diode (Pack of 1000) High Quality

1N4007 Through Hole Diode (Pack of 1000)

Low leakage Current
Low forward voltage drop
High forward surge capability

SKU 1000pcs*D_1N4007 SKU SYS 2329-1000PCS Availability Out of stock

Quantities are confirmed after reviewing your order. Orders are normally prepared and shipped within 3–5 business days. Online availability does not necessarily mean the product is currently available at the branch. تأكيد الكميات بيتم بعد مراجعة الأوردر، وتجهيز وشحن الطلب بيستغرق عادة من 3 إلى 5 أيام عمل. توافر المنتج على الموقع لا يعني بالضرورة توافره داخل الفرع، لذلك اعمل الأوردر مسبقًا لتأكيد الكمية وتجهيزه.

You are already subscribed We will notify you when this product is available again. أنت مشترك بالفعل، وسنرسل لك تنبيهًا عند توافر المنتج.

Fast shipping Delivery across Egypt

Flexible payment Cash and online options

Quantity confirmation Confirmed after order review

Technical support Help choosing compatible parts

Description

1N4007 Through Hole Diode(Pack of 1000) is a PN junction rectifier diode. These types of diodes allow only the flow of electrical current in one direction only. So, it can be used for the conversion of AC power to DC

Package Includes of 1N4007 :

1 x 1N4007 Through Hole Diode(Pack of 1000)

Repetitive Peak Reverse Voltage(V)	1000
RMS Reverse Voltage(V)	700
Non-Repetitive Peak Forward Surge Current(A)	30
Peak Reverse Current(uA)	5
Forward Voltage(V)	1
Average Rectified Output Current(A)	1
Storage Temperature Range	-65°C to +150°C
Length (mm):	5.06
Width (mm):	2.55
Weight (g):	0.1 (approx) (each)
Shipping Weight	1.5 kg
Shipping Dimensions	26 × 8 × 15 cm
