Description

Multi-slot input: AC cable 110-240V 50/60Hz (included), four independent charging and micro computer management system.
Charge current intelligent auto-set of total three levels: 500mA /1000mA/2000mA, 2000mA is fixed only for slot#4.
Multi-functional LCD charging display: for charging progress 25% – 50% – 75% -100%, battery types: Ni-MH 1.2V, Li-Fe 3.2V, Li-ion 3.7V, Li-ion 3.80V (IMR), charging capacity, voltage and current: 0.5A/1A/2A.
Identify Li-ion and Ni-MH batteries automatically and adjust manually the charging mode for LiFePO4 and 3.80V li-ion batteries(IMR)
Refresh for OV battery. It will not charge any battery of 1.65 -2.20V (refresh current can be detected only)
Multi-safety protection function of over-charge and over-discharge, short circuited, polarity reverse and so on. It can smartly identify broken batteries with much more safety.
Charging at constant voltage and current

Specifications:
Input voltage: AC cable 110-240V 50/60Hz
Output voltage:
DC 4.2V for Li-Ion 3.7V
DC 4.35V for Li-Ion 3.8V (IMR)
DC 3.65V for LiFePO4
DC 1.48V for NiMH/NI-Cd
Output current: Li-Ion/IMR/LiFePO4 2000mA*1(only for slot#4),
1000mA*2, 500mA*3  500mA*4
NiMH/NiCd: 1000mA*2, 500mA*3  500mA*4
Constant voltage, cut-off current: less than 100mA
Standby current: less than 15mA
Compatible battery types:
Li-ion / IMR/LiFePO4: 26650, 21700, 20700, 18650, 18490, 18350, 17670, 17500, 16340(RCR123), 14500, 10440
NiMH/Cd: AA, AAA, SC, C
Item color: Black
Plug type: EU/ US (optional)
Material: ABS+ pc
Cable length: 1200mm
Item size: 145 * 95 * 35mm/ 5.7 * 3.7 * 1.4in (L * W * H)
Item weight: 263g (us)/ 275g (eu)
Package size: 175 * 137 * 40mm/ 6.9 * 5.4 * 1.6in (L * W * H)
Package weight: 299 (us)/ 311(eu)

Notes:
1. This charger can charge all cylindrical rechargeable batteries 3.7V Li-Ion , 3.8V IMR, 1.2V Ni-MH/Cd, 3.2VLiFePO4.
2. Pay special attention to the recommended charge current, must avoid charging battery beyond the recommended current limit.
3. Mind heating while charging
4. Remove the charger from power source after charging complete, and remove the battery from the charger at the same time
5. For indoor use only, non-waterproof.

Package list:
1 * Charger
1 * Cable
1 * Instruction
