Description

Micro USB Female SMD 2.0 B type 5 Pin Connector

Micro USB is a miniaturized version of the Universal Serial Bus (USB) interface developed for connecting compact and mobile devices such as smartphones, Mp3 players, GPS devices, photo printers and digital cameras. Micro USB connectors exist or have existed in three forms: micro A, micro B and micro USB 3 USB Type-C has an oblong-shaped plug and is slightly bigger than Micro-USB. It can be inserted either side up. Micro-USB can only be plugged in one way and has two hooks at the bottom to hold the cable in place  This is MICRO USB 5 pin is Type B Mike Patch Straight Plug Adapter. This Adapter Plate consists of an international Micro USB 2.0 B type 5 Pin Connector standard.

It is female micro-USB Plug mostly used to connect the smartphone data cable as well as charger or power supply adapters to interface with your application. It has a wide range of uses. This module is easily transformed into a conventional DIP 2.54mm pin, a great convenience to your application for multipurpose use.

Features:

1. Brand new and high quality.
2. Base Material: FR4.
3. Contact resistance: 30mΩ Max.
4. Insulation resistance: 100 MΩ min.
5. Dielectric strength: 500VAC one min.
6. Insulator material: LCP.

Package Include:

1× Micro USB 2.0 B type 5 Pin Connector
