Out of stock
Push Button Switch NC Normally Closed Red Sign Momentary 22mm XB2-BA42
50.00 EGP
Quantities are confirmed after reviewing
your order. Orders are normally prepared
and shipped within 3–5 business days.
Online availability does not necessarily
mean the product is currently available
at the branch.
تأكيد الكميات بيتم بعد مراجعة الأوردر،
وتجهيز وشحن الطلب بيستغرق عادة من
3 إلى 5 أيام عمل.
توافر المنتج على الموقع لا يعني بالضرورة
توافره داخل الفرع، لذلك اعمل الأوردر
مسبقًا لتأكيد الكمية وتجهيزه.
Fast shipping
Delivery across Egypt
Flexible payment
Cash and online options
Quantity confirmation
Confirmed after order review
Technical support
Help choosing compatible parts
- Description
Description
⊹ Product Features：It is used for controlling signal and interlocking purposes.It is used for controlling the circuit of elecromagnetic starter,contactor,relay and so on.The pushbutttons with indicator are applied to place where signal indicators are needed as well.⊹ Product material：The main body of the push buttons adopts zinc alloy and high-grade anti-flam plastic.The contact adopts special silver alloy in order to enjoy the benefit of high anti-electrical erosion.
| Basic technical parameter of button | Basic technical parameter of signal lamp | |||
| Rated insulation | AC 400V(50Hz/60Hz) | Insulation resistance | ≥50MΩ | |
| Conventional heating current | 10A | Contact resistance | ≤25MinΩ | |
| Insulation resistance | ≥50MΩ | Pf withstand voltage | AC 2.5KV/min | |
| Contact resistance | ≤25MinΩ | Voltage wave | ±20% | |
| Mechanical life | 100×10000 pushbutton | 50×10000 selector switch | Brightness | 60cd/m2 |
| Electrical life | 500×10000 pushbutton | 25×10000 Selector switch | Continuous working life | 10x10000h |
