Save -14% Out of stock BMS 3S 100A Li-no Battery Balance Charging BMS Protection PCB Board-White

BMS 3S 100A Li-no Battery Balance Charging BMS Protection PCB Board-White

Charging Current: 60A
Current Balance: Yes
Ampere balance (Current): 60MA
Voltage balance accuracy: 4.14-4.24V

SKU BMS_3s100A 2Res SKU SYS X6304 Availability In stock

Quantities are confirmed after reviewing your order. Orders are normally prepared and shipped within 3–5 business days. Online availability does not necessarily mean the product is currently available at the branch. تأكيد الكميات بيتم بعد مراجعة الأوردر، وتجهيز وشحن الطلب بيستغرق عادة من 3 إلى 5 أيام عمل. توافر المنتج على الموقع لا يعني بالضرورة توافره داخل الفرع، لذلك اعمل الأوردر مسبقًا لتأكيد الكمية وتجهيزه.

Fast shipping Delivery across Egypt

Flexible payment Cash and online options

Quantity confirmation Confirmed after order review

Technical support Help choosing compatible parts

Description

BMS 3S 100A Li-no Battery Balance Charging BMS Protection PCB Board-White

This protection board is 3s in common use lithium battery protection board (you can adjust for how many strings to be used) Specified chip, stable performance, support disconnection protection, over-current protection, over-discharge protection, overcharge protection, with balance, etc. A common use for “same port” and “different port”, the protection board uses 15 high-power of ultra-low resistance MOS tubes (discharge of 8, charging 7), in the same port mode can support the discharge current 60A, charging current 60A; different port mode discharges current 80A, charging current 60A. Can used for LMO.Ternary lithium battery.LCO(3.7V)battery packs etc.

Features:

Temperature protect: Yes
Disconnect protect: Yes
Shortage protection: Yes
Shortage delay: 100-600 uS
Shortage protect recovery: YES
Charging Current: 60A
Current Balance: Yes

Package Includes:

1 x White 3S 100A Li-no Lithium Battery Protection PCB Board

Single-cell battery overcharge protect voltage:	4.21-4.29 V
Single-cell battery overcharge protect recover voltage:	4.14-4.24V
Overcharge protect delay	1.5-2.5S
Single-cell battery over-discharge protect voltage:	2.72-2.88 V
Overcharge protect Current	100A
Over-discharge protect Current	100A
Over-discharge protect delay	0.5-1.5S
Temperature protect	Yes
Disconnect protect	Yes
Shortage delay	100-600 uS
Charging Current	60A
Ampere balance (Current)	60MA
Voltage balance accuracy	4.14-4.24V
Shipping Weight	0.015 kg
Shipping Dimensions	8 × 7 × 1 cm
