Save -31% Out of stock AT-09 Bluetooth 4.0 UART Transceiver Module CC2541 Zs-040 Compatible with HM-10 with button

AT-09 Bluetooth 4.0 UART Transceiver Module CC2541 Zs-040 Compatible with HM-10 with button

AT-09 Bluetooth 4.0 UART Transceiver Module CC2541 Compatible with HM-10 with button

Ultra-low standby power consumption 90uA~400uA
Range up to 60 meters
Built-in PCB antenna
Power input : 3.6v to 6v DC (6v MAX)

SKU Blue_AT09 V4 SKU SYS x3147 Availability In stock

Quantities are confirmed after reviewing your order. Orders are normally prepared and shipped within 3–5 business days. Online availability does not necessarily mean the product is currently available at the branch. تأكيد الكميات بيتم بعد مراجعة الأوردر، وتجهيز وشحن الطلب بيستغرق عادة من 3 إلى 5 أيام عمل. توافر المنتج على الموقع لا يعني بالضرورة توافره داخل الفرع، لذلك اعمل الأوردر مسبقًا لتأكيد الكمية وتجهيزه.

Fast shipping Delivery across Egypt

Flexible payment Cash and online options

Quantity confirmation Confirmed after order review

Technical support Help choosing compatible parts

Description

AT-09 Bluetooth 4.0 UART Transceiver Module CC2541 Compatible with HM-10 with button

The AT-09 is a module that contains a BLE chip (a CC2540/CC2541). This module allows performing serial communication with the BLE chip thanks to an Rx and a Tx pin. This module is also very similar to the HM-10 module and is also compatible with it. So if you have some experience with the latter, you will get started quickly with the AT-09.

This small size Bluetooth 4.0 TTL transceiver module allows your target device to communicate with your iPhone/iPad, IOS 6 or Android 4.3 above devices. You can set it as a slave or master and use AT command to set the baud rate.

Applications:

Industrial remote control, remote sensing.
POS system, Bluetooth keyboard, mouse, game controllers.
Automobile testing equipment.
Portable, the battery power of medical equipment.
Automated data collection.
Bluetooth remote control toy.
The wireless LED display system.
Bluetooth printer.
Intelligent household, industrial control.

Useful Links:

Tutorials

Package Includes:

1 x AT-09 Bluetooth 4.0 UART Transceiver Module CC2541.

Input Supply voltage (V)	3.6 ~ 6
BLE Chip	CC2540/CC2541
Input Current (μA)	90 ~ 400
Maximum Operating Range (m)	60 ~ 100
Operating Temperature (°C)	-20 ~ 75
Length (mm)	43
Width (mm)	17
Height (mm)	8
Weight (gm)	5
Shipment Weight	0.01 kg
Shipment Dimensions	7 × 5 × 3 cm
