Description

Okdo Lidar HAT Module with Bracket Development Kit for LiDAR_LD06 Raspberry Pi SBC

This is an Okdo Lidar Module with Bracket Development Kit for LiDAR-LD06 Raspberry Pi SBC 54.010012 23-7609. It comes as pictured and does not include any additional parts or accessories.

Features:

• The LiDAR LD06 has adopted TOF (time of flight) ranging technology and can measure distance according to the laser pulse time of flight within a detection distance of 12 meters.
• The LD06 uses first class algorithm logic to achieve 360 degrees environmental detection, autonomous map building and obstacle detection.
• With high-speed wireless data transmission and brushless motors, the LD06 can last for up to 10000 hours.
• The LD06 can achieve high-frequency and high-precision distance measurement and accurate map building indoors and outdoors.
• The LD06 is fully compatible with Raspberry Pi3 A+/B+, Raspberry Pi3 B and Raspberry Pi 4B

Specifications:

• Distance measuring range: 0.02mm – 12m
• Scanning Frequency: 5-13 Hz
• Ranging accuracy: 30mm
• Ranging frequency: 4500Hz
• Scanning Angle: 360 degrees
• Size: 38 x 38 x 33 mm
