Save -25% Out of stock PL2303 TA Download Cable USB to TTL RS232 Module USB to Serial

PL2303 TA Download Cable USB to TTL RS232 Module USB to Serial

Built-in TTL COM PC-PL2303HX Chip.
Standard USB type and TTL 4 pin connector
Simple and Easy way to give USB support to your designs
Available for Linux, Mac, WinCE, and Windows (XP, 7), Win 8
Cable Length: 1M
Net Weight: 30gm

SKU USB_TTL9 PL2303 to TTL RS232 Module SKU SYS X7136 Availability Out of stock

Quantities are confirmed after reviewing your order. Orders are normally prepared and shipped within 3–5 business days. Online availability does not necessarily mean the product is currently available at the branch. تأكيد الكميات بيتم بعد مراجعة الأوردر، وتجهيز وشحن الطلب بيستغرق عادة من 3 إلى 5 أيام عمل. توافر المنتج على الموقع لا يعني بالضرورة توافره داخل الفرع، لذلك اعمل الأوردر مسبقًا لتأكيد الكمية وتجهيزه.

You are already subscribed We will notify you when this product is available again. أنت مشترك بالفعل، وسنرسل لك تنبيهًا عند توافر المنتج.

Fast shipping Delivery across Egypt

Flexible payment Cash and online options

Quantity confirmation Confirmed after order review

Technical support Help choosing compatible parts

Description

This is PL2303 TA Download Cable USB to TTL RS232 Module USB to Serial.

The cable is the easiest way ever to connect to your microcontroller/Raspberry Pi/WiFi router serial console port. Inside the big USB plug is a USB to Serial conversion chip and at the end of the 1M cable are four wire – red power, black ground, white RX into the USB port, and green TX out of the USB port.

The power pin provides the 5V @ 500mA direct from the USB port and the RX/TX pins are 3.3V levels for interfacing with the most common 3.3V logic level chipsets.

Because of the separated pin plugs, this cable is ideal for powering and connecting up to the debug/login console on the Raspberry Pi or BeagleBone Black.

Also handy for hacking WiFi routers to install alternate OS’s, or nearly any other 3.3V logic serial port. This is easier to use than an FTDI cable in many cases because the wires are separated.

Pin Connection

Red: +5 V
Black: GND
White: RXD
Green: TXD

Applications:

Single-chip upgrade solution for Legacy RS232 devices to USB interface
USB to RS232 converters/cables/dongles
Healthcare/Medical USB Interface Data Transfer Cable
Personal Infotainment/Media Player Docking USB Interface
Cellular/PDA USB Interface Data Transfer Cable
Serial-over-IP Wireless Solution
USB Barcode/Smart Card Readers
GPS/Navigation USB Interface
Point-of-Sale (POS) Terminals/Printers
PC Docking Station/Port Replicators
Industrial/Instrumentation/Automation Control USB Interface

Features :

Built-in TTL COM PC-PL2303HX Chip.
Standard USB type and TTL 4 pin connector
Simple and Easy way to give USB support to your designs
Available for Linux, Mac, WinCE, and Windows (XP, 7), Win 8

Package Includes :

1 x PL2303 TA Download Cable USB to TTL RS232 Module.

Model Type:	RS232 Module
Weight (g):	30
Cable Length (m):	1
Shipping Weight	0.033 kg
Shipping Dimensions	10 × 7 × 3 cm
