Save -35% Out of stock Arduino Mega2560 Pro ATMEGA2560-16AU USB CH340G Development Board

Arduino Mega2560 Pro ATMEGA2560-16AU USB CH340G Development Board

The board is compatible with Mega 2560.
excellent solution for developing projects based on ATmega2560.
The board can be powered directly through the Micro USB connector
The maximum output current upon 5V is around 800mA, while on the 3.3V it is about 800mA.

SKU AR_MegaPro CH340G ATMEGA2560-16AU SKU SYS x3356 Availability In stock

Quantities are confirmed after reviewing your order. Orders are normally prepared and shipped within 3–5 business days. Online availability does not necessarily mean the product is currently available at the branch. تأكيد الكميات بيتم بعد مراجعة الأوردر، وتجهيز وشحن الطلب بيستغرق عادة من 3 إلى 5 أيام عمل. توافر المنتج على الموقع لا يعني بالضرورة توافره داخل الفرع، لذلك اعمل الأوردر مسبقًا لتأكيد الكمية وتجهيزه.

Fast shipping Delivery across Egypt

Flexible payment Cash and online options

Quantity confirmation Confirmed after order review

Technical support Help choosing compatible parts

Description

Arduino Mega2560 Pro ATMEGA2560-16AU USB CH340G Development Board

The Mega Pro Embed CH340G / ATmega2560 board is based on the ATmega2560 microcontroller. Built on the Atmel ATmega2560 microcontroller and USB-UART interface chip CH340G. This is a great solution to get your final project on the welding prototype board.

The Mega Pro Embed functionalities are identical to the Mega 2560. Even though it is an Embed board, it is solid as stable as the Mega Board. It uses the original chip, and 16 MHz high-quality quartz resonators are present on the board. The board uses the chip CH340G as the converter UART-USB. It provides a stable data exchange result when you work at a frequency of 12Mhz (requires the driver to be installed on the computer).

You can power the board or power the pins through the MicroUSB connector. The voltage regulator (LDO) can handle input voltages from 6V to 9V (peak 18V) DC. The voltage regulator allows to use up to 18V as an input value, however, we do not recommend exceeding the recommended values aforementioned, since this can lead to excessive heat and damage the device.

Features of Arduino Mega2560 Pro:

The board is compatible with Mega 2560.
excellent solution for developing projects based on ATmega2560.
The board can be powered directly through the Micro USB connector
The maximum output current upon 5V is around 800mA, while on the 3.3V it is about 800mA.

Package Includes:

1 x Mega2560 Pro ATMEGA2560-16AU USB CH340G Intelligent Electronic Development Board

1 x 21 Pin Headers

1 x 16 Pin Headers

1 x 3 Pin Headers

Microcontroller	ATmega2560
Operating Voltage	5V
Input Voltage (recommended)	6-9V
Input Voltage (limit)	12V
Digital I/O Pins	54 (of which 15 provide PWM output)
Analog Input Pins	16
DC Current for 5V Pin	800 mA
DC Current for 3.3V Pin	800 mA
Flash Memory	256 KB of which 8 KB used by bootloader
SRAM	8 KB
EEPROM	4 KB
Clock Speed	16 MHz
Built-in LED	13
Length(mm)	54
Width(mm)	40
Height(mm)	18
Weight(g)	15
Shipment Weight	0.03 kg
Shipment Dimensions	11 × 8 × 3 cm
