Description

ESP32 Development Board CH340 USB Type-C WIFI and Bluetooth

This is the ESP32S-DEV development board based on ESP-WROOM-32, features WiFi + Bluetooth connectivity, onboard USB CH340 and keys. What’s more, all the I/O pins of ESP-WROOM-32 module are accessible via the extension headers. The board has 2x15pin extension headers, which breakout all the I/O pins of the module and 2x keys, used as reset or user-defined

Quick Spec

• ESP-WROOM-32 32-bit 240 MHz microprocessor
• Supply Voltage: 5V
• 2.4 GHz Wi-Fi
• Bluetooth 4.2
• 4 MByte (32Mbit) SPI Flash
• 448 KB ROM
• 520 KB SRAM
• 16 KB SRAM in RTC
• PCB Antenna
• Powered via USB Type-C Connector, or via pin header
• Reset and User/Firmware buttons
• User and Power LED
• USB Type-C connector
• Virtual USB port provided by CH340 for debugging and firmware upgrade
• Assembled with ESP-WROOM-32 module
• Dimensions: 51.5 x 28.5mm

Pin-Out

<

Getting Started with ESP-32

Installing ESP-32 in the Arduino IDE

Resources

• Installing ESP-32 in Arduino IDE
• ESP-32 Arduino Sample Code
• ESP32 WROOM 32 Datasheet
• ESP-32 Which IO Pins Should you use?
• Blinking an LED with ESP-32 – 3 Steps
• Installing MicroPython
• Additional Information
• ESP32-DEV Dimensions and Pin Spacing

Shipping List

• 1 x ESP32 Dev Board CH340 – USB-C
